GPX-C Deigned specially for Consistent highly accuracy printing quality and user friendly operating environment machine from the base to printing section enables high accuracy printing even for large panels, and durability which can maintain printing quality.
GPX-C can Support 50 x 50mm to 610 x 610 mm and PCB Thickness 0.4 to 6.0mm
Positional High Accuracy: ± 0.012mm 6α
Snap off : up to 4mm, Speed : 0.1 to 40mm/Sec
Double squeeze Operational: Metal Squeeze type, 60 degree Print Angle
Alignment Accuracy: ± 0.020mm 6α
Screen Frame Size: 29” x 29”
Automatic width Adjust facility
Dry/Wet + Dry Vacuum Cleaning
Under side clearance of 25.4mm (Using back-up pins)
The AIMEX IIIC is designed especially for component flexibility, PCB flexibility and production flexibility.
The AIMEX IIIC can support large Panels up 50 x 50mm to 508 x 400mm, PCB Thickness 0.4 to 6.0mm size.
Rated Speed 54000 CPH
Configured with FUJI intelligent feeder, which supports to components traceability Functions, Feeder maintenance function & Component exhaust warning using traceability software
Placement Accuracy: ± 30µm @ 3α CPK ≥ 1.00
Built- in Auto and Hybrid calibration ensures placement accuracy to best level all the time during production.
Image Processing through CCD Camera
Configured with Fly vision camera
Offline/Online Programing supported
MS Algorithm function supports to us handle any ODD Shape parts using seek lines
Feeders supports traceability of components using optional FUJItrax Software
Fuji Feeder are of Variable pitch, Electrically Driven, Common for Paper and Emboss, Common for Parts 0402 mm(01005”) to 3225mm (1210”) parts size.
Feeder can be loaded and unloaded during machine Production mode for quick parts replacement.
The most efficient heat transfer Reflow.
8 Top and 8 Bottom Heating Zones & 2 Cooling Zones
In build PCB Reflow profile facility±
350°C (maximum operating temperature for Lead-Free Approved Reflow)
Conveyor Type : Chain + Mesh
Belt 20" Belt Conveyor (19" [483mm] usable width and 0.5" [12.5mm] pitch)
Conveyor width adjustment: Motorized
Left-to-Right (transport direction)
Conveyor height adjustable: Maximum 900mm ±20mm
Individual Cell Inlet and Exhausts
Flux Flow Control (flux evacuation system)
Emergency Stops (one on each corner of the system)
Over-Temperature Safety System (bi-metalic sensors)
PDR IR based BGA rework station is High-Precision and accuracy machine for µBGAs, CSPs, BGAs, QFNs, QFPs, PLCCs, SOICs Standard Rework
Advanced features are as below
Advanced Focused IR based component heating
Quartz IR PCB Preheating
Precision component Pick & Place Mechanism
Precision PCB Handling
Component Temperature control system
PCB Temperature Control system
Advanced Software based Auto Thermal profile Process Control
Camera/Prism based BGA/CSP QFN Alignment System
